Dust Particle Sensor

The Dust Particle Detection Unit represents a cutting-edge solution for the detection of particulate dust. It offers accurate readings of two particle sizes, PM2.5 and PM10, with a concentration range of 0 to 1000 micrograms per cubic meter of air (µg/m³). This unit is designed to communicate seamlessly with any SCADA system via Modbus RS485 protocol. It holds the highest level of certification, being I/S and SANS 15.15.3 certified, ensuring compliance with the most stringent industry standards. The Dust Particle unit can be easily installed in underground environments. Additionally, the unit features a robust 16-pin plug, simplifying the wiring process for all necessary peripherals.

The RTSE Dust Particle Detection unit is meticulously engineered to monitor the air quality you breathe. It offers exceptional accuracy and a long service life. With ±15% accuracy for PM2.5 readings, the RTSE Dust Particle unit guarantees reliable and precise detection of airborne particulates, providing peace of mind for years to come.

Key Features
  • Voltage Input: 12V

  • Operating Current: 350mA (approximate)

  • Display: LCD display for real-time gas readings

  • Compliance: Certified as "Explosion Protected" EX ia I and SANS 15.15-3, suitable for hazardous locations

  • Digital Output: 2 Digital outputs

  • Relay Output: 1

  • Communication: 2-wire RS485 Modbus communication

  • Device ID Range: 1 to 50 (Includes a fire patrol push button for convenient on-board ID change and alarm response acceptance)

  • Alarm Indication: High-brightness LED cluster with red/green alarm indication, accompanied by an amber cluster for average calibration indication during startup.
